Denon AVR-S970H 8k 7.2 Channel Receiver

Denon AVR-S970H 8k video 7.2 Channel Receiver

Enjoy incredible 8K video and enveloping 3D audio from the AVR-S970H. Fill medium-size rooms with more refined sound from a 7.2 or 5.2.2 setup with Dolby Atmos and DTS:X. And with HEOS® Built-in, wirelessly stream online music and share with HEOS-enabled speakers in other rooms.

Key Features-

• Powerful sound : Fill a medium-size room with powerful, more refined sound.
• Immersive 3D audio : Feel fully enveloped in your music or movie sound.
• Geared for 8K : Enjoy amazing video quality from the latest 8K technology available.
• Music streaming throughout your home : With HEOS Built-in, easily access streaming music and share with HEOS-enabled speakers in other rooms.

High performance discrete 7-channel amplifier

Discrete high-current amplifiers on all channels to deliver up to 90W per channel (at 8 ohms, 20-20kHz, THD 0.08%) enough power to drive any speaker.

Immersive audio experience

Get immersed in music and movies with Dolby Atmos® and DTS:X® plus Dolby Surround and DTS Neural:X upmixer to optimize older content.

Advanced 8K home theater

8K video is supported on three of six HDMI inputs and one of the two outputs. Enjoy easy video compatibility and great picture quality with HLG, HDR, Dolby Vision, HDR10+, and Dynamic HDR pass-through.

HEOS Built-in technology

Stream music wirelessly to compatible HEOS-enabled components from a variety of streaming services. Add Denon Home speakers to more rooms and control it all with the HEOS app.

TECHNICAL SPECIFICATIONS

Multichannel Surround

DTS HD Master, DTS:X, DTS:X Pro	Yes, Yes, No
DTS Neo:X, DTS Neural:X	No, Yes
DTS Virtual:X	Yes
Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music	Yes, Yes, Yes, Yes
Dolby ProLogic Ilz, Dolby Surround	No, Yes
Multichannel Stereo	Yes
Max. Number of Processing (Pre-Amp) Channels	7.1

Sound Enhancements

Discrete Power Amplifier	Yes
Pure Direct	Yes
Audyssey	MultEQ
Audyssey Dynamic EQ, Dynamic Volume	Yes, Yes
Compressed Audio Restorer	Yes

Network

Media Server	Yes
HEOS Wireless Multi-Room Technology	Yes
Alexa / Google Voice Assistant / Apple HomePod	Yes, Yes, Yes
Lossy Formats: MP3, WMA, AAC	Yes, Yes, Yes
Lossless Formats: FLAC, ALAC, WAV	Yes, Yes, Yes
Lossless Formats: FLAC HD, WAV, ALAC (all 192kHz/24 bit)	Yes, Yes, Yes
DSD Audio Streaming	Yes (2.8/5.6MHz)
AirPlay 2	Yes
TuneIn	Yes
Spotify Connect	Yes
Pandora	Yes
SiriusXM	Yes
Roon Tested	Yes
HEOS App Control	Yes
Compatible with Remote APP for Smart Phones	Denon 2016 AVR Remote
Ethernet Ports	Yes
Wi-Fi	Yes
Bluetooth	Yes

HDMI

HDMI Inputs: Back, Front	6, No
HDCP2.3 support	Yes
HDMI Outputs: Main, Zone	2 / No
HDMI 2.1: 8K/60Hz AB, 4K/120Hz AB	Yes, Yes
HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR	Yes , Yes, Yes, Yes, Yes
ALLM (Auto Low Latency Mode) Pass-through for gaming	Yes
Variable Refresh Rate, Quick Frame Transport, Quick Media Switching	Yes, Yes, No
3D Signal Pass-through	Yes
8K Signal Pass-Through, Scaling, GUI Overlay	Yes, Yes, Yes
Audio Return Channel (ARC), Enhanced ARC	Yes, Yes
Auto LipSync	Yes

Multi-Room / CI

Multi-Room Zones	2
Zone Audio Source: HDMI; Optical, Coax, Network, USB; Analog	Yes (2ch), Yes (2ch), Yes, Yes
Zone Audio Output: Speaker, Pre-Out	Yes, No
IP Control, RS232 Control, Web Control, App Control	Yes, No, Yes, Yes
Remote In / Out	No, No
HDMI Diagnostics	Yes

Others

Auto Speaker Setup by Microphone	Audyssey MultEQ
Front Display	1-Line FLD
GUI Languages	3
Setup Assistent	Yes
Quick Select Plus, Quick Select	Yes, No
Variable Crossover	Yes
Optimized Bass Redirection	Yes
ECO Mode	Yes
Auto Power Off	Yes
Sleep Timer	Yes

Inputs/Outputs

HDMI In, Out	6, 2
Multi-Room Video Out: Video, HDMI	No, No
Analog In, Out	4, No
Phono (MM) In	Yes
Digital In: Optical, Coaxial	2, 1
Multi-Room Out: Analog, Digital	No, No
Multichannel Pre-out	Yes (0.2)
Subwoofer Out	2
Speaker Terminal: Gold-Plated Screw, Regular Screw	No, Yes
Number of Speaker Terminals	7
Multi-Room Speaker Terminal	Assignable
Front Inputs: Audio, Composite, Digital (Opt), HDMI, USB	No, No, No, No, Yes
USB Audio, Made for iPod, Made for iPhone	Yes, No, No
AM/FM Tuner	Yes

Specifications

Number of Power Amps	7
Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive)	90W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	125W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	185W

General

System Remote Control	RC-1253
Pre-Programmed, Learnable, LCD Display	No, No, No
Power Consumption in W	500
Power Consumption No-Sound (ECO On / Off) in W	35W/75W
Standby Consumption in W	0.1
CEC Standby Consumption in W	0.5
Network Standby Consumption in W	Less than 2.0
Maximum Dimensions Antenna: Horizontal: (W x D x H) in Inches Antenna: Vertical: (W x D x H) in Inches W/O Antenna: (W x D x H) in Inches	17.1 x 13.4 x 6.6 ( 17.1 x 13.4 x 9.3 ) 【 17.1 x 13.0 x 6.6 】
Weight in LBS	21.0
Weight in LBS (Packaging)	25.4
