Marantz NR7000N Integrated Stereo Amplifier

Marantz NR7000N Integrated Stereo Amplifier

Key Features

Power To Suit Your Audio Preference

2ch fully discrete current feedback integrated Hi-Fi amplifier; 60W per channel (8-ohm, 20Hz – 20kHz)

Wide Range Of Connectivity

Four analog inputs, one analog output, one coaxial input, two optical digital inputs and one USB-A for high resolution audio files

Advanced Marantz Sound

Wider dynamic range with lower distortion for the output stage from Marantz’s latest HDAM-SA3 technology

Flexibility For All Configurations

Tone control to tune sound to your exact specifications and dedicated subwoofer output for evenly dispersed bass, no audible peaks or dips



Product Specifications

Channels	2
Current Feedback Topology	Yes
Full balanced circuitry architecture	No
Double Mono Power Amp construction	No
Phono EQ: Standard / Marantz Musical / Marantz Musical Premium	Yes / No / No
Digital in: USB-B / optical / coaxial / USB-A	No / 2 / 1 / 1
Sample Rate digital In	192 kHz / 24-bit
USB-A: DSD / WAV / FLAC / AIFF / ALAC	<=5.6 / 192 / 192 / No / 192
USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6	No
USB-B PCM sample rate	No
Asynchronous mode rear USB	No
Bit-perfect transmission	No
Ground isolator for DAC Mode operation	No
Tuner: DAB / DAB+ / FM (RDS)	No
Bluetooth / aptX / NFC	Yes / No / No
Streaming audio from PC	Yes
Wi-Fi / Wired LAN	Yes / Yes
Internet radio	Yes
AirPlay 2	Yes
Windows Play to	Yes
Spotify Connect* / Tidal* / Deezer* / others *	Yes / Yes / Yes / Yes
Amazon Prime Music* / Pandora*	Yes / Yes
HEOS Multiroom and Streaming	Yes
Voice Control – Works with Amazon Alexa	Yes
Voice Control – Google Assist / Apple Siri	Yes
Voice Control – Microphone built-in	No
DSD-Audio network streaming	Yes
Lossy formats: MP3 / WMA / AAC	Yes / Yes / Yes
Lossless formats: DSD / FLAC HD 192/24 / ALAC 96/24 / WAV 192/24 / AIFF	Yes / Yes / Yes / Yes / No
Gapless Playback	Yes
Remote APP: iDevice / Android	Yes / Yes
Analog Mode	No
HDAM version	SA3, SA2
Power Transformer: Toroidal / El	Yes / No
High Grade Audio Components	Yes
Customised Components	Yes
Symmetric PCB Layout	Yes
Aluminium extrusion heat sink	Yes
Copper Plated Chassis	No
Tri Tone Control (Bass / Mid / Treble)	No
Balance / Bass / Treble / Loudness	Yes / Yes / Yes / No



Audio Inputs	4
Digital in: USB-B / optical / coaxial / USB-A	No / 2 / 1 / 1
Phono Input: MM / MC	Yes / No
Audio Outputs	1
Balanced In / Out	No
Pre-out / Main-in	subwoofer / No
Power Amp Direct IN	No
HDMI: inputs / outputs	No
Gold Plated Cinch	Yes
Speaker A / B	No
Speaker Terminals	Marantz SPKT-1+
Number of terminals	2
D-Bus	Yes
Floating Control Bus (3.5 mm mono jack x 2)	No
Headphone Out	Yes
Headphone Gain Control (low / mid / high)	No



Power Output (8 / 4 Ohm RMS)	60 W / 80 W
Frequency response	5 Hz-100 kHz
Total Harmonic Distortion	0.02%
Damping Factor	100<
Input Sensitivity: MM	2 mV / 47 kOhm
Input Sensitivity: MC	No
Signal to Noise Ratio: MM/MC	87 dB / No
Input Sensitivity: High level	200 mV / 20 kOhm
Input Sensitivity: Balanced High level	No
Signal to Noise Ratio: High level	115dB(2V input)
Input Sensitivity: Power Amp Direct IN	No
Signal to Noise Ratio: Power Amp Direct IN	No
