Description

Denon AVCX-4700H 9.2 Channel 8K Audio Video Receiver

Denon AVCX-4700H is a 9.2 channel 8K AV Amplifier with 200W per channel fully supports 3D audio formats like Dolby Atmos, DTS:X, IMAX Enhanced and Auro-3D. Comes equipped with the latest in HDMI specifications such as 8K/60Hz and 4K/120Hz** pass-through, VRR, ALLM, Dynamic HDR, HDR10+ and eARC support.

Its can stream popular music services like Spotify, TuneIn Internet Radio, Amazon Music HD, TIDAL and more wirelessly via Bluetooth, Apple AirPlay 2 and Wi-Fi with HEOS Built-in. Enjoy your MP3 collection and even Hi-Res audio formats (WAV, FLAC, ALAC and DSD 2.8/5.6 MHz files) via USB or Network. The Denon AVC-X4700H works with Amazon Alexa, Google Assistant and Apple Siri for effortless voice control.

• High-performance discrete 9-channel amplifier: Delivers a dynamic 200W per channel to provide a trusted, precise and powerful Denon sound experience.
• Full 8K/60Hz and 4K/120Hz** support: With the latest HDMI support, enjoy 8K quality video from your 8K source devices. Supporting one 8K input and two 8K outputs allows for 8K/60Hz and 4K/120Hz** pass-through. 8K upscaling is available on all 8 HDMI inputs.
• The latest in HDMI support: With 8 advanced HDMI inputs with full HDCP 2.3 support and 3 HDMI outputs, connect to all your favourite media devices and output up to 3 monitor displays so you can enjoy from any room.
• Enjoy your favourite immersive 3D audio: Enjoy immersive, 3D audio from sources like Dolby Atmos, Dolby Atmos Height Virtualization, DTS:X, DTS Virtual:X and Auro-3D.
• IMAX Enhanced Technology: Delivers a true IMAX theatre experience at home.
• Built-in Bluetooth and Wi-Fi with 2.4GHz/5GHz dual band support: Solid wireless network connectivity even in congested environments.
• Bluetooth audio transmitter: Enjoy your favourite audio through your Bluetooth headphones late at night or with your family member who is hearing impaired. This feature supports Bluetooth-only playback as well as simultaneous playback with connected speakers.
• Smart TV connectivity: Control the Denon AVC-X4700H with your TV remote via HDMI CEC.

Denon AVCX-4700H AVR Specifications-

Technical specifications-

DTS HD Master / DTS:X -Yes

DTS Neo:X / DTS Neural:X -Yes

DTS Virtual:X -Yes

Dolby TrueHD / Dolby Atmos/Dolby Atmos Height Virtualization -Yes

Dolby ProLogic Ilz / Dolby Surround -Yes

Multichannel Stereo -9

Max Number of Processing (Preamp) Channels-9

Dolby Height Virtualization -Yes

Discrete Power Amplifier -Yes

Audyssey- MultEQ XT

Audyssey Dynamic EQ / Dynamic Volume -Yes

Compressed Audio Restorer -Yes

Media Server -Yes

HEOS Wireless Multi-Room Technology -Yes

Bluetooth Re-transmit for Bluetooth headphones  -Yes

Alexa / Google Voice Assistant / Apple HomePod -Yes

Lossy Formats: MP3 / WMA / AAC -Yes

Lossless Formats: FLAC / ALAC / WAV -Yes

Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 -Yes

DSD Audio Streaming -Yes

FLAC HD 192/24 -Yes

WAV192/24-Yes

ALAC192/24 -Yes

Internet Radio-Yes

HEOS App Control -Yes

Ethernet Ports -Yes

Wi-Fi -Yes

Bluetooth -Yes

Other Streaming Services *- Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix

HDMI Inputs: Back / Front -7/1

HDCP 2.3 support -Yes

HDMI Outputs: Main / Zone -2/1

GUI Overlay on HDMI -Yes

HDMI: 3D / 4K / CEC / ARC / Insta Prevue -Yes

Enhanced ARC -Yes

HDR / HLG / Dolby Vision -Yes

ALLM (Auto Low Latency Mode) Pass-through for gaming -Yes

3D Signal Pass-through -Yes

4K Signal Pass-through / Scaling / GUI Overlay -Yes

CEC -Yes

Audio Return Channel -Yes

Auto LipSync -Yes

Multiroom zones-2

Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog -Yes

Zone Audio Output: Speaker / Preout -Yes

IP Control /  Web Control / App Control -Yes

Remote In-Yes

HDMI Diagnostics-Yes

Auto Speaker Setup by Microphone-Yes

FL Display-c 2Lines

Graphic User Interface – GUI -Advance

GUI Languages-9

Setup Assistant-Yes

Variable Cross Over-Yes

Auto Power Off- Yes

Sleep Timer-Yes

Number of Power Amps -9

Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive) -105W

Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)-135W

Power Output (6 ohm, 1 kHz, 10% 1ch Drive)-180W

Composit In/Out-3/2

HDMI In/Out -8/3

Analog In/Out- 6

Phono(MM)In- Yes

Digital In-Optical/Digital – 2/2

Multiroom out-analog/digital-2

Multichannel preout- Yes

Subwoofer out- 2 / Yes

Multi-Room Speaker Terminal-Yes

Speaker A / B-Yes

Bi-amp Drive-Yes

Front Inputs:  HDMI / USB

USB Audio-Yes

AM/FM Tuner-Yes

Maximum Dimensions
Antenna: Horizontal: (W x D x H) inMM– 434 x 389 x 167
Antenna: Vertical: (W x D x H) in MM –   434 x 389 x 236
W/O Antenna: (W x D x H) in MM -434 x 379x 167
